Compacting to specifications is critical for soil, landfill, and paving applications. Cat compactors are specifically designed for all compaction operations.

• Operating Weight 6003.0 lb
• Maximum Weight at Front Drum 2857.0 lb
• Maximum Weight at Rear Drum 3147.0 lb
• Standard Compaction Width 47.0 in
• Curb Clearance 20.0 in
• Turning Radius Inside Drum Edge 8.0 ft
• Ground Clearance 11.0 in
• Static Linear Load 63.0 lb/in
• Travel Speed - Maximum 7.5 mph
• Gross Power 36.2 hp
• Engine Model C1.5
• Overall Length 101.0 in
• Wheelbase 71.0 in
• Overall Width 52.0 in
• Drum Diameter 28.0 in
• Drum Width 47.0 in
• Maximum Machine Height 106.0 in
• Centrifugal Force per Drum - Maximum 7374.0 lb
• Centrifugal Force per Drum - Minimum 3282.0 lb
• Frequency 63/55/42 Hz (3,780/3,300/2520 vpm)
• Nominal Amplitude - High0.021 in
• Fuel Tank Capacity 17.0 gal
• Water (Spray) Tank Capacity: 62.0 gal
